Human-on-a-Chip technologies could dramatically accelerate drug testing and get vital drugs into the market faster to save lives.


Interested in the Exponential Future? Join our XPotential Communityconnect, watch a keynote, or browse my blog.

When it comes to testing the efficacy of untested drugs to see whether or not they work why bother trialling them on people when you can use a tiny plastic Lego brick instead? So goes the thinking behind of the researchers around the world who are all busy developing what’s known as “Human-on-a-Chip” technologies that I’ve discussed before.


Scientists may have identified the genes responsible for ageing


Over the past couple of years researchers have created everything from a heart on a chip to a placenta on a chip, and even a tumour on a chip – all to help accelerate drug research and testing. And now, in lieu of our ability to create fully synthetic human cells, researchers have developed a “Human Cell Membrane-on-a-Chip” that allows continuous monitoring of how drugs and infectious agents interact with our cells, and they’ve told us that these chips may soon be used to test potential drug candidates for COVID-19, the deadly pandemic that’s still sweeping the world and which so far, despite best efforts, still doesn’t have a vaccine.

The researchers, from the University of Cambridge, Cornell University and Stanford University, say their device can mimic any cell type – bacterial, human or even the tough cells walls of plants. Their research recently pivoted to how COVID-19 attacks human cell membranes and, more importantly, how it can be blocked.


World first as scientists just turn human blood cells into human eggs


According to the researchers behind the new technology the membranes have been formed on chips while “preserving the orientation and functionality of the cell membrane” and have been successfully used to monitor the activity of ion channels, a class of protein in human cells which are the target of more than 60 percent of approved pharmaceuticals. The results are published in two recent papers in Langmuir and ACS Nano.

Cell membranes play a central role in biological signalling, controlling everything from pain relief to infection by a virus, acting as the gatekeeper between a cell and the outside world. The team set out to create a sensor that preserves all of the critical aspects of a cell membrane – structure, fluidity, and control over ion movement – all without the time consuming steps needed to keep a cell alive.

The device uses an electronic chip to measure any changes in an overlying membrane extracted from a cell, enabling the scientists to safely and easily understand how the cell interacts with the outside world.


Scientists successfully transferred memories between two snails


The device integrates cell membranes with conducting polymer electrodes and transistors. To generate the on-chip membranes, the Cornell team first optimised a process to produce membranes from live cells and then, working with the Cambridge team, coaxed them onto polymeric electrodes in a way that preserved all of their functionality. The hydrated conducting polymers provide a more ‘natural’ environment for cell membranes and allows robust monitoring of membrane function.

The Stanford team optimised the polymeric electrodes for monitoring changes in the membranes. The device no longer relies on live cells that are often technically challenging to keep alive and require significant attention, and measurements can last over an extended time period.

“Because the membranes are produced from human cells, it’s like having a biopsy of that cell’s surface – we have all the material that would be present including proteins and lipids, but none of the challenges of using live cells,” said Dr Susan Daniel, associate professor of chemical and biomolecular engineering at Cornell and senior author of the Langmuir paper.


Jeff Bezos' Blue Origin outlines plans for first deliveries to the Moon in 2023


“This type of screening is typically done by the pharmaceutical industry with live cells, but our device provides an easier and cheaper alternative,” said Dr Róisín Owens from Cambridge’s Department of Chemical Engineering and Biotechnology, and senior author of the ACS Nano paper. “This method is compatible with high-throughput screening and would reduce the number of false positives making it through into the R&D pipeline.”

“The device can be as small as the size of a human cell and easily fabricated in arrays, which allows us to perform multiple measurements at the same time,” said Dr Anna-Maria Pappa, also from Cambridge and joint first author on both papers.

To date, the aim of the research, supported by funding from the United States Defense Research Projects Agency (DARPA), has been to demonstrate how viruses such as influenza interact with cells. Now, DARPA has provided additional funding to test the device’s effectiveness in screening for potential drug candidates for COVID-19 in a safe and effective way.


Scientists have grown a brain in a jar


Given the significant risks involved to researchers working on SARS-CoV-2, the virus which causes COVID-19, scientists on the project will focus on making virus membranes and fusing those with the chips. The virus membranes are identical to the SARS-CoV-2 membrane but don’t contain the viral nucleic acid. This way new drugs or antibodies to neutralise the virus spikes that are used to gain entry into the host cell can be identified. This work is expected to get underway on 1 August.

“With this device, we are not exposed to risky working environments for combating SARS-CoV-2. The device will speed up the screening of drug candidates and provide answers to questions about how this virus works,” said Dr Han-Yuan Liu, Cornell researcher and joint first author on both papers.

Future work will focus on scaling up production of the devices at Stanford and automating the integration of the membranes with the chips, leveraging the fluidics expertise from Stanford PI Juan Santiago who will join the team in August.


Electrical brain stimulation rejuvenates memory by 50 years


“This project has merged ideas and concepts from laboratories in the UK, California and New York, and shown a device that works reproducibly in all three sites. It is a great example of the power of integrating biology and materials science in addressing global problems,” said Stanford lead PI Professor Alberto Salleo.

Source: University of Cambridge
